| Conductivity Measurement in a wide range from 0-10 microsiemens/prm to 0 to 100000 or more us is made easy in open channel ,rivers etc by this weather proof wall mounting type instrument. Ultra bright 1” LED for display of parameter value. Isolated current output( 974 CI ),One/Two control outputs ( 974 C- 2) and combination of current and control outputs ( 974 C I- 2) are possible. |
|
| Specifications |
|
| Range |
0-100 /0-1000 /0-10000 /0-100000 uS or any range on request |
| Accuracy |
0.50FS% |
| Resolution |
1 uS |
| Zero Adjustment |
+/- 15% of Zero |
| Span Adjustment |
+/- 15% of Span |
| Temperature Compensation |
Automatic upto 100°C |
| Enclosure |
Field Mountable 295X215X115 SMC Box Pipe line/ Bracked Mounted |
| Explosion Proof Enclosure |
On Request |
| Current Output |
4-20 mA Isolated into 600 ohms resistive load |
| Alarm Output |
1 or 2 as option |
|
| Power Supply |
230 VAC 50Hz (110 VAC on request) |
|
|
|
 |
|
|
|
